| Brand Name: | Juneng Machinery |
| Model Number: | NCB 12/0.5 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 60 days |
Sanitary High Flow Centrifugal Pump / Vegetable Oil Pump Anti Corrosion
High Flow Centrifugal PumpApplication
Oil refining Petrochemical
Chemical
Power plant
Environmental protection
Marine
Pharmaceutical industry etc.
High Flow Centrifugal Pump Specifications:
|
Model
|
Flow
m3/h
|
Pressure
Mpa
|
Motor Model
|
Motor Power
KW
|
Assembly style
|
Outline dimension
LxWxH (mm)
|
|
NCB1.2/0.3
|
1.2
|
0.3
|
Y90L-6
|
1.1
|
Belt driven
or
Coupler
driven
or gear box driven
|
234x140x140
|
|
NCB1.8/0.3
|
1.8
|
0.3
|
Y100L-6
|
1.5
|
254x153x153
|
|
|
NCB3/0.3
|
3
|
0.3
|
Y132S-8
|
2.2
|
254x153x153
|
|
|
NCB6/0.5
|
6
|
0.5
|
Y100L-4
|
3
|
700x420x323
|
|
|
NCB8/0.5
|
8
|
0.5
|
Y100L-4
|
3
|
700x420x323
|
|
|
NCB12/0.5
|
12
|
0.5
|
Y132M-4
|
4
|
800x550x420
|
|
|
NCB16/0.5
|
16
|
0.5
|
Y160M-6
|
5.5
|
800x550x420
|
|
|
NCB20/0.5
|
20
|
0.5
|
Y160L-6
|
7.5
|
800x550x420
|
|
|
NCB12/0.7
|
12
|
0.7
|
Y160M-4
|
7.5
|
990x780x510
|
|
|
NCB18/0.7
|
18
|
0.7
|
Y160L-6
|
11
|
990x780x510
|
|
|
NCB24/0.5
|
24
|
0.5
|
Y160M-4
|
11
|
990x780x510
|
|
|
NCB30/0.5
|
30
|
0.5
|
Y160L-4
|
15
|
990x780x510
|
|
|
NCB15/1.5
|
15
|
1.5
|
Y180L-6
|
15
|
1230x1009x740
|
|
|
NCB20/0.7
|
20
|
0.7
|
Y160L-6
|
11
|
1230x1009x740
|
|
|
NCB25/0.7
|
25
|
0.7
|
Y180L-6
|
15
|
1230x1009x740
|
|
|
NCB35/0.5
|
35
|
0.5
|
Y160L-4
|
15
|
1230x1009x740
|
|
|
NCB40/0.5
|
40
|
0.5
|
Y200L-6
|
18.5
|
1340x1022x650
|
|
|
NCB50/0.5
|
50
|
0.5
|
Y200L-6
|
18.5
|
1340x1022x650
|
|
|
NCB60/0.5
|
60
|
0.5
|
Y200-6
|
22
|
1340x1022x650
|
|
|
NCB70/0.5
|
70
|
0.5
|
Y225M-6
|
30
|
1340x1022x650
|
|
|
NCB80/0.5
|
80
|
0.5
|
Y250M-6
|
37
|
1590x1356x840
|
|
|
NCB100/0.5
|
100
|
0.5
|
Y280S-6
|
45
|
1590x1356x840
|
|
|
NCB120/0.5
|
120
|
0.5
|
Y280M-6
|
55
|
1590x1356x840
|
Application:
It is applied to convey liquid from all kinds of light or volatility to deep sticky, even to half-solid. It is widely used in petroleum, chemistry, oil, paint etc.
Product competitive advantage:
The inner gearing principle is adopted for this pump. The annular and external gear pitch circles closely lean against one side, the other side is separated by covering with “ crescent plate” .
The annular gear driver the external gear for the same direction rotation. It has the advanced structure, fine quality, small volume, large flow, low noise, durable service life.
