Sanitary High Flow Centrifugal Pump / Vegetable Oil Pump Anti Corrosion

Product Details:
Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: ISO
Model Number: NCB 12/0.5
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard Wooden Case
Delivery Time: 60 days
Supply Ability: 40 set / months
Contact Now

Detail Information

Name: High Flow Centrifugal Pump Drive: Motor
Motor Speed: 290 Rpm Motor Power: 4 Kw
Pressure: 0.5 Mpa Flow: Anti Corrosion

Product Description

Sanitary High Flow Centrifugal Pump / Vegetable Oil Pump Anti Corrosion



High Flow Centrifugal PumpApplication



Oil refining Petrochemical
Chemical
Power plant
Environmental protection
Marine
Pharmaceutical industry etc.



High Flow Centrifugal Pump Specifications:



Model
Flow
m3/h
Pressure
Mpa
Motor Model

Motor Power
KW
Assembly style
Outline dimension
LxWxH (mm)
NCB1.2/0.3
1.2
0.3
Y90L-6
1.1
Belt driven
or
Coupler
driven
or gear box driven
234x140x140
NCB1.8/0.3
1.8
0.3
Y100L-6
1.5
254x153x153
NCB3/0.3
3
0.3
Y132S-8
2.2
254x153x153
NCB6/0.5
6
0.5
Y100L-4
3
700x420x323
NCB8/0.5
8
0.5
Y100L-4
3
700x420x323
NCB12/0.5
12
0.5
Y132M-4
4
800x550x420
NCB16/0.5
16
0.5
Y160M-6
5.5
800x550x420
NCB20/0.5
20
0.5
Y160L-6
7.5
800x550x420
NCB12/0.7
12
0.7
Y160M-4
7.5
990x780x510
NCB18/0.7
18
0.7
Y160L-6
11
990x780x510
NCB24/0.5
24
0.5
Y160M-4
11
990x780x510
NCB30/0.5
30
0.5
Y160L-4
15
990x780x510
NCB15/1.5
15
1.5
Y180L-6
15
1230x1009x740
NCB20/0.7
20
0.7
Y160L-6
11
1230x1009x740
NCB25/0.7
25
0.7
Y180L-6
15
1230x1009x740
NCB35/0.5
35
0.5
Y160L-4
15
1230x1009x740
NCB40/0.5
40
0.5
Y200L-6
18.5
1340x1022x650
NCB50/0.5
50
0.5
Y200L-6
18.5
1340x1022x650
NCB60/0.5
60
0.5
Y200-6
22
1340x1022x650
NCB70/0.5
70
0.5
Y225M-6
30
1340x1022x650
NCB80/0.5
80
0.5
Y250M-6
37
1590x1356x840
NCB100/0.5
100
0.5
Y280S-6
45
1590x1356x840
NCB120/0.5
120
0.5
Y280M-6
55
1590x1356x840



Sanitary High Flow Centrifugal Pump / Vegetable Oil Pump Anti Corrosion

Application:



It is applied to convey liquid from all kinds of light or volatility to deep sticky, even to half-solid. It is widely used in petroleum, chemistry, oil, paint etc.



Sanitary High Flow Centrifugal Pump / Vegetable Oil Pump Anti Corrosion



Product competitive advantage:



The inner gearing principle is adopted for this pump. The annular and external gear pitch circles closely lean against one side, the other side is separated by covering with “ crescent plate” .



The annular gear driver the external gear for the same direction rotation. It has the advanced structure, fine quality, small volume, large flow, low noise, durable service life.
