Automatic Industrial Cream Separator , Centrifugal Solids Separator

Place of Origin China(Yixing, Jiangsu)
Brand Name Juneng Machinery
Certification CE、 ASME U、ISO9001
Model Number NYB-25
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details plywood case
Delivery Time 10-30 days
Payment Terms TT, L/C, D/A, D/P, Western Union
Supply Ability 40 set / months

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Industrial Cream Separator Shell Diameter ∅1100
Space Between Filter Leaf 70 Inlet/outlet Caliber DN50
Overflow Port DN40 Application Oil
High Light

high temperature filter bag

,

vertical leaf filter

,

ce industrial cream separator

Leave a Message
Product Description

Automatic Industrial Cream Separator , Centrifugal Solids Separator



Industrial Cream Separator Working Principle



Industrial Cream Separator belongs to stainless steel woven mesh filter. It is the new generation filtration equipment that we developed referencing foreign technology, the filter has unique and compacted design, and high efficiency. It does not consume the filter cloth, filter paper or filter cartridge, just uses a little filter aid, so the filtration cost is low. And the machine is easy to operate, maintain and clean. Manual discharging and auto discharging are available according to customer's requirement. The filter area ranges from 2m2 to 200 m2. The housing material can be carbon steel or stainless steel to meet clients' different needs.



Industrial Cream Separator competitive advantage:

  • With no cloth and filter paper, it greatly reduces filtration costs.
  • The fully closed operation is environmentally friendly without material loss
  • Vibration residue falling greatly reduces labor intensity and realizes continuous operation
  • Residue discharging through the pneumatic valve greatly reduces labor intensity of workers.
  • The residues in the liquids are subject to activated carbon (carclazyte) filtering or bleaching filtering. It can completely replace the plate and frame filter and is a revolutionary device in the filter industry.



Industrial Cream Separator Outline form & assembly size



Model Shell diameter Space between filter leaf Inlet/outlet caliber Overflow port Discharge port Height Floor Spare
NYB-25 ∅1100 70 DN50 DN40 DN500 3020 1810×1430
NYB-30 ∅1200 70 DN50 DN40 DN500 3150 2030×1550
NYB-36 ∅1200 70 DN65 DN50 DN500 3250 2030×1550
NYB-40 ∅1300 70 DN65 DN50 DN600 3350 2130×1560
NYB-45 ∅1300 70 DN65 DN50 DN600 3550 2130×1560
NYB-52 ∅1400 75 DN80 DN50 DN600 3670 2230×1650
NYB-60 ∅1500 75 DN80 DN50 DN600 3810 2310×1750
NYB-70 ∅1600 80 DN80 DN50 DN600 4500 3050×1950
NYB-80 ∅1750 80 DN80 DN50 DN600 4500 3210×2100
NYB-90 ∅1850 80 DN80 DN50 DN600 4650 3300×2200



Main technique



Model Filtration area ㎡ Filter cake volume L Treatment Capacity Work Pressure Mpa Work temperature ℃ Machine volume L Machine weight Kg
Oil Resin Beverage Rated pressure Max pressure
NYB-25 25 500 5-7 12-19 16-21 0.1-0.4 0.5 ≤150 1900 2000
NYB-30 30 600 6-8 14-23 19-25 2300 2500
NYB-36 36 720 7-9 16-27 23-31 2650 3000
NYB-40 40 800 8-11 21-34 30-38 2900 3200
NYB-45 45 900 9-13 24-34 36-44 3200 3500
NYB-52 52 1040 10-15 27-45 42-51 3800 4000
NYB-60 60 1200 11-17 30-52 48-60 4500 4500
NYB-70 70 1400 12-19 36-60 56-68 5800 5500
NYB-80 80 1600 13-21 40-68 64-78 7200 6000
NYB-90 90 1800 14-23 43-72 68-82 7700 6500



Industrial Cream Separator Application:

Oil industry: crude oil, bleached oil, hydrided oil, radonized oil, stearin, fatty acid, etc.
Petrochemical products: diesel oil, lubricating oil, paraffin and mineral moil products
Organic chemical products: various organic acid, ester, benzene and aldehyde
