High Speed Milk Cream Separator Machine With PLC Controller Operating Stability

Product Details:
Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: CE
Model Number: DHN616
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Standard Wooden Case
Delivery Time: 60 days
Payment Terms: TT
Supply Ability: 40 set / months
Contact Now

Detail Information

Name: Milk Cream Separator Machine Feature: High Speed
Controller: PLC Controller Advantage: Operating Stability
Warranty: 1 Year Voltage: 220V/380V

Product Description

High Speed Milk Cream Separator Machine With PLC Controller Operating Stability



Milk Cream Separator Machine Principle



The Liquid-Solid Disc Stack Centrifuge is introduced to the rotating centrifuge bowl from the top via a stationary inlet pipe, and is accelerated in a distributor before entering the disc stack. It is between the discs that the separation of the two liquid phases (or one liquid phase) and the solids takes place. For two liquids and solid separation type, the oil phase (light liquid phase) moves towards the centre of the bowl and is discharged by a paring disc. The water phase (heavy liquid phase) leaves the bowl over the top disc and through a paring disc. The heavier solids phase is collected at the bowl periphery, from where it is discharged intermittently. The solids discharge is achieved by a hydraulic system below the separation space in the bowl, which at preset intervals forces the sliding bowl bottom to drop down, thus opening the solids ports at the bowl periphery. The bowl is mounted on a vertical spindle driven by a vertically mounted motor, via a belt drive.



Milk Cream Separator Machine Application:


DHN series separator is mainly used in milk clarifying industry. This type separator also can be used in apple juice, orange juice, vegetable juice, tea drinks , coffee , beer and other industry which need to separating two different density liquid.


Milk Cream Separator Machine advantage:



1, High rotating speed

2, Operating stability

3, Completely sealed up of the inlet and outlet system




Milk Cream Separator Machine Specifications:



Model

Treatment
 capacity (L/H)

Inlet
pressure (Mpa)

Outlet
pressure (Mpa)

Motor
power (Kw)

Weight(Kg)

Outline
dimension (mm)

DHN616

25000-35000

0.1

0.3

37

3000

2185*1728*2082





Introduction of Company:



Juneng Group is a large scale manufacturer of industrial products in China with its subsidiaries namely Juneng Machinery(China) Co., Ltd and Jiangsu Juneng Machinery Co., Ltd. The group principally engaged with the in-house research & development as well as manufacturing of various industrial filters, separators and pumps. The Company is proud to be the leader in such industry with Fats industry, Chemical industry, Pharmaceutical industry, Beverage industry, Petrol - chemical industry, and now is one of the well-know producers and suppliers in the world. The company now has its three production bases with a total capacity of 280,000 square meters in Nanjing City and Yixing City of Jiangsu province, permanent workforces not less than 1300 people and the production line is well equipped with more than 1500 units of advanced production equipment and test instrumentation.
