Stainless Steel Low Noise Starch Gluten Centrifugal Separators Online Blue Color

Product Details:
Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: CE、ISO9001
Model Number: DPF445
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard Wooden Case
Delivery Time: 60 days
Payment Terms: TT
Supply Ability: 40 set / months
Contact Now

Detail Information

Alias: Nozzle Separator Moving Part: Drum
Drum Speed: Max.5200 Rpm Drum Material: Duplex Steel
Disk Material: SS316L Disk Quantity: 120~160 Pieces
Nozzle Diameter: 1.8~3.4mm Nozzle Quantity: 20

Product Description

blue color stainless steel low noise starch gluten centrifugal separators online



Specifications



DPF445 separator is a high speed, high precision, closed and efficient separation equipment, mainly used in starch, fermentation liquid, algae, chemical and pharmaceutical industries, solid-liquid two-phase separation and concentration.



All parts in contact with materials are made of advanced stainless steel materials (or specific acid-resistant materials), which can effectively reduce the corrosion of the separated materials and parts in contact with the surface, meeting the requirements of food hygiene.



The separated light phase materials are output by centripetal pump, and the maximum output pressure can reach 0.30mpa. This machine adopts the form of feeding, the light liquid is output by the centripetal pump, and the requirement for the inlet pressure of the material is low.



Model :DPF800 CAPACITY : 22-130 T/h

DPF935 CAPACITY: 45-260T/H.



Stainless Steel Low Noise Starch Gluten Centrifugal Separators Online Blue Color



Product Description:



People will crash and separate the mature crops depend on their physical properties, then obtain starch. So the starch separator is the key in the process of starch extraction.

In the starch separation process, the separator rotates in high speed then creates the centrifugal force, so the separation efficiency is improved.



At the same time maximize the production efficiency. We devote ourselves to make Juneng starch separator to the most professional and efficient in starch processing industry, it collects all the advantages of various separator such as small vibration, large capacity, stable running and so on.



It’s mainly used in pre-concentration starch, separation of starch and gluten, concentration of gluten (protein) , clarify of process water in the after step and so on.



Model Throughput capacity (T/H) Max. bowl speed(RPM) Motor power (KW) Weight (kg)
DPF445 20-35 4500-5200 30 1400
DPF520 25-45 4650 37 1550
DPF600 30-60 2850-4800 75/55 3500
DPF800 22-115 2750-3300 132/110 7800
DPF935 45-225 2250-3050 250/220 11000
DPF960 45-250 2250-3000 250/220 11500
DPF1000 45-300 2250-2950 300/220 12000
DPF1170 50-500 2200-2800 315/250 15000



Application:



Each separator is a nozzle centrifuge designed for continuous discharge of solids. It is used for classifying, concentrating and washing solids , and for clarifying liquids that contain relatively high solids concentrations. They are widely used in the starch industry for processes that include primary starch separation, gluten thickening, and middling concentration.

Graining process :  Corn / Cassava/ wheat/ potato starch



Product competitive advantage:



1, Big diameter of drum, large area of disk, strong capability of production(separation), excellent effect of separation.

2, Adopting top-suspension driving, which makes the separator with high rotation stability, largely improves the using life of bearings and main shaft.

3, Adopting automatic control of lubricating oil circuit, which protects and prolongs the using life of driving system.
