Sus304 Centrifugal Transfer Pump For Oil Refining Petrochemical , Chemical

Place of Origin China(Yixing, Jiangsu)
Brand Name Juneng Machinery
Certification CE、ISO9001
Model Number GXG 800
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Standard Wooden Case
Delivery Time 60 days
Supply Ability 40 set / months
Product Details
Power Electric Application Chemical,food
Fuel Electric Pressure High Pressure
Standard Or Nonstandard Standard Usage Oil,beverage
High Light

slurry centrifugal pump

,

High Pressure Pump

Leave a Message
Product Description

Sus304 Centrifugal Transfer Pump For Oil Refining Petrochemical , Chemical



Centrifugal Transfer Pump description:



Thermal Oil Pumps, or hot oil pumps as they are otherwise known, are designed for the movement of heat-transfer oils under high temperature conditions. High temperature oil pumps such as these are primarily used to feed an oil burner or furnace, or as a hot oil circulation pump for circulating the fuel as part of a larger boiler feed or heating system.



stainless steel anti-corrosive centrifugal pump, food grade centrifugal pump using high quality stainless steel and axes seal. This kind of pump has merit of well strcture, reliable anti-corrosion, well seal performance, easy repair and use low power.



Centrifugal Transfer Pump Application:



LHB180 centrifugal mixing pump is mainly for mixing oil with alkaline, oil with phosphoric acid, and oil with water in the continuous refining process for vegetable oil, and will send the oil to next operation in certain pressure. And it can also be used for mixing two liquids in other industries. This pump can mix fully, run steadily, has very low noise, is indispensable for continuous refining process of vegetable oil.



Centrifugal Transfer Pump advantage:



LHB180 centrifugal mixing pump mainly consists of drum, centripetal pump, inlet/outlet unit and motor.

Two (or more) liquids mixed quantitatively are fed to the inlet and enter into the drum, they are mixed fully due to centrifugal force and 6 cavities in the drum, the centripetal pump at the outlet converts the dynamic pressure head of the liquid rotating at high speed into static pressure head (0.10~0.2MPa) and sends it to the next operation.

Centrifugal Transfer Pump Specifications:



Model

Treatment Capacity (T/D)

Motor Power ( Kw)

LHB150

30~150

3

LHB160

80~180

3

LHB180

100~200

5.5

LHB180A

200~400

7.5

LHB180B

400~600

11
