High Pressure Centrifugal Transfer Pump With Strong Concentric Casing

Place of Origin China(Yixing, Jiangsu)
Brand Name Juneng Machinery
Certification CE、ISO9001
Model Number IHK40-25-180
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Standard Wooden Case
Delivery Time 60 days
Supply Ability 40 set / months
Product Details
Name Centrifugal Transfer Pump Fuel Electric
Theory Centrifugal Pump Feature High Pressure
Structure Single-stage Pump Casing Strong Concentric Casing
High Light

waste oil transfer pumps

,

High Pressure Pump

Leave a Message
Product Description

High Pressure Centrifugal Transfer Pump With Strong Concentric Casing



Centrifugal Transfer Pump description:



1. All spare parts interchangeable with most of the international Brand pump which helps customer

to source spare parts easily

2. Thick, Strong Concentric casing provides extended life over conventional volute designs. The

Concentric design minimizes turbulence and abrasive wear.

3. Pump casing made from hard ductile iron alloy, increased abrasion resistant capability compared

to competitors pump.

4. Wide open-vane impeller creates lower axial thrust for improved bearing life.

5. Pump impeller made from hard ductile iron alloy, extended life over competitors design.

6. Antiloosening impeller lock bolt to eliminate pump damage in case of improper motor hook-up.

7. High quality no-adjustment mechanical seal to provide zero leakage and longer operation life.

8. Replaceable shaft sleeve prevents shaft wear.





QC/Technical Support



1, Every company deeply understand that quality is the basic weapon for an enterprise to win. Quality is one of the factor that helped the business to achieve success, so we strive to provide qualitative business.

2, Our Quality Control department is comprised of experienced engineers, technicians and QC inspectors. The best products from the high reputation company and will do better than any other company.



Centrifugal Transfer Pump advantage:



1, The structure of the pump conforms to international standard. The impellers are tape open structure. It’s suitable for the liquid with high solids concentration and various suspension.

2, It’s horizontal split type and back pullout construction. It needn’t to dismount pipes and motor when maintenance.

3, Shaft seal introduce mechanical seal and power seal. It’s safety and reliable.



Centrifugal Transfer Pump Specifications:



Model

Flow Q m3/h

Lift H

m

Speed

r/min

Power

kW

NPSHr

m

IHK40-25-180

6.3

40

2900

4

2.3

IHK50-32-200

12.5

50

2900

7.5

2.3

IHK65-40-250

25

80

2900

18.5

2.3
