Peeler Centrifuge Starch Centrifugal Separators Customized Color
|Control||Both Automatic And Manual Are Available||Operation||Dehydration,washing And Discharging|
|Drum Speed||1550 Rpm||Loading Capacity||150 Kg|
SS304 Peeler Centrifuge,
Full Automatic Starch Centrifugal Separators,
Customized Color Peeler Centrifuge Starch Centrifugal Separators
Siphonic Centrifuge is a type of full-automatic centrifuge with continuously working and batch operation. According to the structure, it can be divided into Siphonic Scraper Centrifuge (GKH series) and common scraper centrifuge (GK series).
GKH siphon scraper discharging centirfuge designed on the basis of GK horizontal scraper discharging centrifuge.
The machine is controlled by PLC and regulates speed by frequency convertorm and braking system applies both dynamic braking and regenerative braking.
According to the predetermined procedures, such as feeding, separating, washing, discharging and mesh washing are all under according speed(or full speed).
The scraper centrifuge can be switched between automatic and manual operation, so it can realize the periodic cyclic operation of feeding, dehydration, washing and discharging of the feed material.
Compared with common scraper centrifuge, the sophonic scraper centrifuge has siphonic force like vacuum, so it has better production capacity and separation effect. Especially, it is suitable for the feed material which has small solids, high viscosity, slow filtration and that needs to wash the filter cake.
GKH series siphonic centrifuge is especially used in the occasion of the higher production, lower moisture in residue of the cake and sufficient washing.
It is widely used in industry area of the solid-liquid separation of the raw material and intermediate products, such as foodstuff, pharmacy, chemical, national defence and so on.
|VC natrium||Calcium phosphate|
|Drum diameter||800 mm , about 31.5 inch|
|Drum length||450 mm , about 17.7 inch|
|Drum speed||1550 rpm|
|Maximun separation factor||1070|
|Motor power||45 Kw|
|Loading capacity||150 Kg|
1 ) This centrifuge has higher production capacity than common scraper centrifuge and the moisture content of filter cake is lower.
2 ) Material for the components touching the products and the mother liquid can be chose and supplied by the customers according to the erosion of the products. Manufacturers should assist customers to make reasonable choices. Final decision is subject to the attachment of the contract. Commonly the material can be 0Cr19Ni9,321,316L,TA2,C276 and duplex steel.
3 ) The adoption of PLC and speed regulation by frequency convertor makes the stepless speed regualtion and braking of the machine possible. The operations of the machine are totally automatically.
4 ) Several interlock control devices highly improve the security of the machine.
5 ) Floating platform and shock absorber need to be installed to the bottom of the centrifuge to reduce damages of vibration to the plant and equipment.
1 . Compliance to delivery lead time
2 . 12 months guarantee period from machine arriving date.
3 . The customer could get trained by our experienced tecnician
4 . We always keep certain inventory level of spare parts, which means the replacement can be sent to you timely
ISO 19001 : 2005, ISO 14001 : 2015, OHSAS 18001 : 2007,
ASME U 38793
