Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste

1.Introduction Decanter centrifuge is a mechanical equipment which utilize the principle of centrifugal and sedimentation and can carry out continual separate the suspend liquid with density difference. 2.Product structure and operation principle Operation principle : Drum and screw rotate at a ...

Tags:

dewatering centrifuge operation

sludge decanter centrifuge

centrifuge oil separator

Product Details

Highlight:

Kitchen Waste Decanter Centrifuge Machine

PLC Scroll Discharge Decanter Centrifuge

Industrial Decanter Centrifuge 3 Phase

Material: Stainless Steel

Type: Centrifuge

Condition: New

Marketing Type: Hot Product 2021

Warranty: 1 Year

Core Components: PLC，Motor, Pressure Vessel, Bearing

Voltage: Design For Different Country

Power: According To The Model

Weight: According To The Model

Dimension(L*W*H): Depend On Model Choosing

Drum Diameter: Depend On Model Choosing

After Warranty Service: Video Technical Support, Online Support

Basic Properties

Place of Origin: Jiangsu,China

Brand Name: Juneng

Certification: CE/ISO

Model Number: LW

Trading Properties

Minimum Order Quantity: 1 set

Price: USD15000~100000/set

Payment Terms: L/C, T/T

Supply Ability: 20 sets/month

Product Description

1.Introduction

Decanter centrifuge is a mechanical equipment which utilize the principle of centrifugal and sedimentation and can carry out continual separate the suspend liquid with density difference.

2.Product structure and operation principle

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 0

Operation principle : Drum and screw rotate at a certain different speed . The feed enters the drum through a stationary inlet tube and is accelerated smoothly by an inlet rotor . The resulting centrifugal forces make the solids collect on the wall of the drum . Screw conveyor continual moving the solid to conical end of drum , discharge through discharge port after dried in the dry area , however , light liquid forms the inner layer and effusion through overflow port of drum , then discharge through liquid outlet port .

3.Main specification and technological parameters

Model	Drum diameter mm	Inlet liquid capacity㎥/h	Power of main/auxiliary motor Kw	Weight Kg	Dimension (max) mm
LW250	250	1-4	11/4	1200	2650720900
LW(F)250	250	1-4	11/4	1200	2650720900
LW250(W)	250	1~5	11/4	1300	2750720900
LW350	350	5~15	22/5.5	2000	35859801238
LW(F)350	350	5~15	22/5.5	2000	35859801238
LW350(W)	350	5~18	15/5.5	2200	34121090950
LW(S)350	350	2~10	22/5.5	2000	36769801238
LW450	450	5~20	30/11	3000	438010801360
LW(F)450	450	5~20	30/11	3000	438010801360
LW450(W)	450	5~28	30/11	3200	438010801360
LW(S)450	450	5~15	37/11	3200	419510801360
LW520	520	10~26	45/15	5000	484011601465
LW(F)520	520	10~26	45/15	5000	484011601465
LW520(W)	520	10~35	16742	5000	484011601465
LW550W	550	10-45	20394	6500	503813881578
LW650A	650	7-9T	110	8000	440722801340
LW650(W)	650	25-60	75/22	8000	550022801340
LW720A	720	8-10T	132/160	11000	441032801450
LW720(W)	720	35-85	110/30	13000	560032801450

*** F: Ex-proof, W:Waste water, S: Three phase FS: Ex-- proof and three phase

4. Application area

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 1

5.Track records

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 2

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 3

7.Main features

• All parts coming into contact with the product are made of stainless steel.

• 3-phase AC motor for controlled torque starting via frequency converter

• Approximately 80 to 90 % of the oil is recovered.

• Low personnel costs due to continuous and automatic operation.

• Highest g-force for higher solids output

• Adjustable bowl speed via VFD

• Automatic adjustment of differential speed via VFD

• Two motor drive

• Belts for both primary motor and secondary motor

8.Packing & Delivery

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 4

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 5

9.1 Our service

1)Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 6

2)After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 7

3)After-sales Service Technical Team.

Our company has set up a professional after-sales service technical team. All sell-offs products shall have engineer to guide installation, assist debugging and train operators until they have mastered them.

9.2 Juneng Group

Juneng Machinery (China)Co., Ltd., established in 2006, is a professional manufacturer engaged in the research, development, production, sale and service of Filter, Separator, Decanter centrifuge and pump. We have four factories which located in Nanjing and Yixing City with convenient transportation access.

Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In recent years, our company has introduced a series of advanced equipment including Filter, Separator, Decanter centrifuge and pump.

In addition, we have obtained CE certificates, ASME U certificate and ISO 9001 certificate. And Selling well in all cities and provinces around China, our products are also exported to clients in such countries and regions as USA,German, Korea,Japan, Pakistan, Malaysia, Singapore, Vietnam and so on.

We also welcome OEM and ODM orders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 8

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 9

Juneng Machinery (China) Co., Ltd in Nanjing

We are devoted to centrifuges and dryers, which could used in various industries, such as environmantel protection, food industry, chemical industry and pharmaceutic industry etc.

Commercial Cooperation and Exchange:

1. Focuse on international collaboration in technical aspect and commercial

2. Advance the management system and experance from other countries,such as USA, Canada, Germany, Russia etc.

Track Records:

1. With the outstanding track records, our products are widely applied into different industries

2. The key factors of our success are to constantly fulfilling customer's requirement and exceed their ecpection.

3.We are loking forward to your guidance, opinion and suggestions that would be a long term mutual beneficially business relationship.

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 10

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 11

9.3 Certifications

Recently years, we achieve plenty of honors and we have obtained various certifications such as CE certificates, ASME U certificate and ISO 9001 certificate.

Environmental Protection Scroll Discharge Decanter Centrifuge for Kitchen Waste 12

9.4 Our market & customers
