quality Biodiesel and glycerin high speed continuous centrifuge separator factory
quality Biodiesel and glycerin high speed continuous centrifuge separator factory
quality Biodiesel and glycerin high speed continuous centrifuge separator factory
quality Biodiesel and glycerin high speed continuous centrifuge separator factory
quality Biodiesel and glycerin high speed continuous centrifuge separator factory

Biodiesel and glycerin high speed continuous centrifuge separator

Biodiesel and glycerin high speed continuous centrifuge separator Product Application A common view has been formed globally that waste oil and hogwash oil can be transformed into biological diesel oil. This not only solve the problems related to food safety, but also generates considerable economic ...
Tags:

oil separator machine

disc stack centrifuges

water oil separators
Product Details
Product Name: Biodiesel And Glycerin High Speed Continuous Centrifuge Separator
Voltage: 380V Or Other
Power: 22kw
Weight: 2200kg
Dimension(L*W*H): 1850x1550x2050
Material: Stainless Steel 304
Operation: Automatic Continuous Operation

Basic Properties

Place of Origin: Jiangsu,China
Brand Name: Juneng
Certification: ISO/CE
Model Number: DHSY470

Trading Properties

Minimum Order Quantity: 1 set
Price: USD10000-50000/set
Payment Terms: L/C, T/T
Supply Ability: 20 sets/month
Product Description

Biodiesel and glycerin high speed continuous centrifuge separator

Product Application

A common view has been formed globally that waste oil and hogwash oil can be transformed into biological diesel oil. This not only solve the problems related to food safety, but also generates considerable economic benefits. Juneng has carried out close cooperation with relevant institutes and universities to make the centrifugal separation technology play an irreplaceable role in the purification process of waste oil, and the technology has been successfully applied in more than thirty projects at home and abroad.



Successful applications:
1, Separation of methyl ester, glycerin, catalyst, de-soap, methanol
2, Methyl washing
3, Extraction of fatty acids

4, Glycerol desalination

Model
Treatment capacity (L/H)
Inlet pressure (Mpa)
Outlet pressure (Mpa)
Motor power (Kw)
Weight(Kg)
Outline dimension (mm)
DBSY204
700-2000
0.05
0.1-0.25
4
408
810*850*1350
DHSY360
1000-2500
0.05
0.1-0.25
7.5
1280
1500*1150*1500
DHSY470
4000-7000
0.05
0.1-0.3
15
1880
1800*1200*1800
DHSY550
6000-15000
0.05
0.1-0.3
22
2200
1850*1550*2050
DHSY700
8000-25000
0.05
0.1-0.3
37
3300
2050*1700*2300
Biodiesel and glycerin high speed continuous centrifuge separator 0
Biodiesel and glycerin high speed continuous centrifuge separator 1
Biodiesel and glycerin high speed continuous centrifuge separator 2
Biodiesel and glycerin high speed continuous centrifuge separator 3
Biodiesel and glycerin high speed continuous centrifuge separator 4

Main Features

1. High speed, stable operation,

2. fully closed of inlet and outlet system,

3. low noise,good separation, high oil rate,

4. fully automatic control ,easy to operate.

5. Low cost of operation, maintenance and serving
Certifications
Biodiesel and glycerin high speed continuous centrifuge separator 5
Detailed Images
Biodiesel and glycerin high speed continuous centrifuge separator 6

Machine Parts

Name: Disc of drum

Brand: Juneng

Original: China

Domestic famous engines, strong driving force

Main Features

Name: Shaft
Brand: Juneng
Original: China
Domestic famous engines, strong driving force

Biodiesel and glycerin high speed continuous centrifuge separator 7
Our Service
Biodiesel and glycerin high speed continuous centrifuge separator 8
Biodiesel and glycerin high speed continuous centrifuge separator 9

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Biodiesel and glycerin high speed continuous centrifuge separator 10
Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
