Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel

Place of Origin Jiangsu,China
Brand Name Juneng
Certification ISO/CE
Model Number GXG-2800
Minimum Order Quantity 1 set
Price USD36000-200000/set
Packaging Details seaworthy packing
Delivery Time 60 work days
Payment Terms L/C, T/T
Supply Ability 20 sets/month
Product Details
Product Name GXG Series Multi-functions Filtering, Washing , Drying (three In One ) Filter Press Function Filtering,drying,washing
Application Industrial Machinery Filter Media Liquid Filtration
Material Carbon Steel, Stainless Steel 304/316, Hastelloy Type Filtering & Drying
High Light

Liquid Filtration Agitated Nutsche Filter Dryer

,

Industrial Agitated Nutsche Filter Dryer

,

carbon steel anfd filter dryer

Leave a Message
Product Description

GXG series multi-functions filtering, washing , drying (three in one ) filter press



1.Product Description

GXG series multi-functions filtering, washing , drying (three in one ) machine is a solid-liquid equipment with the functions of filtration, washing, drying reaction and residue discharging automatically,which is mainly composed of rotating device, filter body, mixing system, lifting mechanism, slag discharge mechanism, filter bed system and other components

Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 0



2.Main applications

It is widely used in fine chemical, petroleum, foodstuff, printing, pharmaceutical industries, Glyphosate, Penicillin and so on.



Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 1



3.Main technological parameters

Model Filtration area m2 Shell
diameter (mm)
Work
pressure (Mpa)
Nominal
volume (m3)
Filter cake
height (mm)
GXG-600 0.28 600 -0.1~0.3 0.2 150
GXG-800 0.5 800 -0.1~0.3 0.5 180
GXG-1200 1.1 1200 -0.1~0.3 1.3 250
GXG-1600 2.0 1600 -0.1~0.3 2.8 350
GXG-2000 3.1 2000 -0.1~0.3 4.8 400
GXG-2400 4.5 2400 -0.1~0.3 6.5 450
GXG-2600 5.3 2600 -0.1~0.3 8.7 450
GXG-2800 6.0 2800 -0.1~0.3 12 450
GXG-3000 7 3000 -0.1~0.3 13 500
GXG-3200 8 3200 -0.1~0.3 14.5 500
GXG-3400 9 3400 -0.1~0.3 15 500
GXG-3600 10 3600 -0.1~0.3 20 500
GXG-3800 11.3 3800 -0.1~0.3 23 500



4.Advantages

1, Full enclosed filter, no leakage, no pollution
2, Solid-liquid separation can be realized under pressure or vacuum state. Filter cakes evenly distributed when filtering which has good effect.
3, Stirring system can stepless speed regulating and multi-function work. It can enlarge furthest for the cake space, thus filter cake can be fully cleaned; the time of drying is reduced greatly, with high efficiency.
4, Discharge valve can discharge automatically which can lower labor intensity.
5, Especially suitable for the material that large solid content, and recovering liquid phase and solid phase respectively.
6, Adopting horizontal placing filter material, one time completely filtering no remains. Filter material has unique sealing structure which is easy to be changed.
7, Anticorrosion three in one system is made of special material which can be suitable for multiform anticorrosion medium.
8, Stirring, mixing , beating , reacting, washing and multiform process working can be practiced in the body and it can carry out full automatic control.




5.Detailed Images

Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 2

Machine Parts

Name: Inside of shell

Brand: Juneng

Original: China

Domestic famous engines, strong driving force

Main Features

Name: Brush
Brand: Juneng
Original: China
Domestic famous engines, strong driving force

Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 3

6.Our company

Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 4

Branch of Juneng in Nanjing

Juneng Company now has its three production bases with a total capacity of 280,000 square meters in Nanjing city and Yixing City , permanent workforces not less than 1100 people and the production line is well equipped with more than 2000 inits of advanced production equipment and test Instrumentation .



Certifications

Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 5

7.Our Service
Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 6
Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 7

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

7.Packing & Delivery
Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 8
Packaging
Size
163 (L) * 131 (W) * 177 (D)
Weight
950 kg



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Industrial Liquid Filtration Agitated Nutsche Filter Dryer Carbon Steel 9
Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
