Energy Saving Horizontal Decanter Centrifuge Stainless Steel Stable Operation

Introduction

Horizontal decander centrifuge is a mechanical equipment that utilizes the principle of centrifugal settling to continuously separate materials with density differences in suspension.

The equipment has a compact structure, continuous operation, stable operation, strong adaptability to separated materials, large production capacity, and convenient maintenance. The centrifuge adopts dual frequency conversion drive, which is easy to operate and adjust operating parameters; In terms of energy conservation, when the auxiliary motor is working, it can also play a power generation function. By using the DC line of the sub motor to compensate for the current generated by the auxiliary motor to the main motor, it has energy-saving benefits.

Product structure and operation principle

The basic principle is that the drum and the conveying screw rotate at a certain differential speed at high speed, and the material is continuously introduced into the spiral pushing inner cylinder through the feeding pipe. After acceleration, it enters the drum, and under the action of the centrifugal force field, the heavier solid phase deposits on the drum wall to form a sediment layer. The feeding screw feeder continuously pushes the deposited solid matter to the cone end of the drum, dehydrates it in the drying area, and is discharged from the machine through the slag discharge port. The lighter liquid phase forms an inner liquid ring, which continuously overflows from the overflow port at the large end of the drum and is discharged from the machine through the liquid outlet. This machine continuously completes processes such as feeding, settling, separation, dehydration, and unloading under full speed operation.

Main specification and technological parameters
