Auto Cake Discharging Horizontal Pressure Leaf Filters For Dewaxing Of Sunflower Oil

Certification CE、 ASME U、ISO9001
Model Number WYB
Minimum Order Quantity One set
Price USD1000-100000
Delivery Time 60 days
Payment Terms TT, L/C
Supply Ability 40 set / months

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Place Of Origin Jiangsu , China Brand Name Juneng Machinery
Packaging Details Seaworthy Packing Model Type WYB
After-sales Service Provided Engineers Available To Service Machinery Overseas Cake Discharge Vibration
Moc Carbon Steel , Stainless Steel Design Code ASME , GB
High Light

horizontal leaf filter

,

horizontal plate filter

Leave a Message
Product Description

Auto Cake Discharging Horizontal Pressure Leaf Filters For Dewaxing Of Sunflower Oil



Application:

Food industry : Syrups, edible oils, dewaxing , decolour, degrease

Chemical industries: Sulphur, aluminum sulfate, Polyaluminum chloride, plastic, dyestuff intermediate, bleaching liquid, lubricant additives and intermediate and high pressure polyethylene, etc.

Dry, semidry cake and clean filtrate recovery.







Product description:

This product is of novel design, the main body of filter consists of filtration tank, screen, end-plate pullout device, automatic dreg discharging device, etc. During filtering, the filter aid is mixed up with material in the mixing cylinder then transmitted by pump onto the filter screen to form a filter cake layer. Once the stable filter cake is realized, the minute filter aid particles provide countless micro passages, which entrap the suspended impurity and let the clear liquid through. Therefore the real filtration is realized through the cake layer. In case that the filter cake over the surface of filter screen reaches certain thickness, the feeding shall be stopped, and compressed air or steam shall be employed to blow dry the cake, and clean the filter screen the discharge , the vibration dreg discharging device shall be switched on, the dregs shall be unloaded because of weight and vibration. As to sticky filter cake, manual help shall be provided to clean up the dregs.







Product competitive advantage:

1, Fully hermetic filter , no leakage, no pollution.

2, Filtering gauze flakes can be pulled out automatically, and easy to be inspected and cleaned.

3, As the leaves filtering on both sides, large filtration area and solids holding capacity can be obtained.

4, Automatically residue discharging by which labor can be largely reduced.

5, Controlled by hydraulic thus automation is to be.

6, A large filtration area and large solids holding capacity can be obtained .



Product Specifications:

Area series ( ㎡)

Shell diameter series ( mm)

Work pressure ( Mpa)

Work temperature
(℃)

Proximate treatment
capacity (T/H·㎡)

5, 10, 15, 20, 25, 30, 35, 40,
45, 50, 60, 70, 80, 90, 100, 120,
140, 160, 180, 200

900, 1200, 1400, 1500, 1600,
1700, 1800, 2000

0.4

150

Oil

0.2





Beverage

0.8





History:



Juneng Group was established at 1987. It has 23 year history. Now its three production bases with a total capacity of 280000 square meters in Nanjing City and Yixing City of Jiangsu Province.



Juneng’s success is contributed by the commitment of every member of the Company. In addition, the specialty and potential of each member is being respected and disinterred.
