Oil Horizontal Pressure Leaf Filter For Food Industries No Leakage

Product Details:
Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: CE、 ASME U、ISO9001
Model Number: WYB-100
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Standard Wooden Case
Delivery Time: 60 days
Payment Terms: TT
Supply Ability: 40 set / months
Contact Now

Detail Information

Material: Stainless Steel,carbon Steel Warranty: 1 Year
Application: Liquid Filtration,Oil Type: Horizontal
Product Name: Horizontal Pressure Leaf Filter Usage: Liquild Filter

Product Description

Oil Horizontal Pressure Leaf Filter For Food Industries No Leakage



Horizontal Pressure Leaf Filter Application

  • Dry, semidry cake and clean filtrate recovery.
  • Chemical industries:Sulphur, Aluminum sulfate, Polyaluminum, chloride, plastic, dyestuff intermediate, bleaching liquid, lubricant Additives and intermediate and high pressure polyethylene, etc.
  • Food industries:Syrups,edible oils, dewaxing, decolour, Degrease.

Horizontal Pressure Leaf Filter description:



This product is of novel design, the main body of filter consists of filtration tank, screen, end-plate pullout device, automatic dreg discharging device, etc. During filtering, the filter aid is mixed up with material in the mixing cylinder then transmitted by pump onto the filter screen to form a filter cake layer. Once the stable filter cake is realized, the minute filter aid particles provide countless micro passages, which entrap the suspended impurity and let the clear liquid through. Therefore the real filtration is realized through the cake layer. In case that the filter cake over the surface of filter screen reaches certain thickness, the feeding shall be stopped, and compressed air or steam shall be employed to blow dry the cake, and clean the filter screen the discharge , the vibration dreg discharging device shall be switched on, the dregs shall be unloaded because of weight and vibration. As to sticky filter cake, manual help shall be provided to clean up the dregs.



Horizontal Pressure Leaf Filter advantage:



1, Fully hermetic filter , no leakage, no pollution.

2, Filtering gauze flakes can be pulled out automatically, and easy to be inspected and cleaned.

3, As the leaves filtering on both sides, large filtration area and solids holding capacity can be obtained.

4, Automatically residue discharging by which labor can be largely reduced.



Company Service:



We sincerely offer various fittings for import and domestic separator users. Our professional personnel will give you help and consultation at any time.



Repair and Maintenance:



We sincerely offer various fittings for import and domestic separator users. Our professional personnel will give you help and consultation at any time.



Train:



Juneng Company provides parts and repair, maintenance as well as techical advice for the demestic and import separator in long time. We guarantee the quality of every maintenance and service.



Horizontal Pressure Leaf Filter Specifications:



Area series ( ㎡)

Shell diameter series ( mm)

Work pressure ( Mpa)

Work temperature
(℃)

Proximate treatment
capacity (T/H·㎡)

5, 10, 15, 20, 25, 30, 35, 40,
45, 50, 60, 70, 80, 90, 100, 120,
140, 160, 180, 200

900, 1200, 1400, 1500, 1600,
1700, 1800, 2000

0.4

150

Oil

0.2





Beverage

0.8
