Double frequency conversion control horizontal decanter centrifugal with capacity 5~18m3/h

Product Details:
Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: CE、ISO9001
Model Number: LW350
Payment & Shipping Terms:
Minimum Order Quantity: One set
Packaging Details: Standard Wooden Case
Delivery Time: 30 days
Payment Terms: TT
Supply Ability: 20 set / months
Contact Now

Product Description

Double frequency conversion control horizontal decanter centrifugal with capacity 5~18m3/h
Product description:
Decanter centrifuge is a mechanical equipment which utilize the principle of centrifugal and sedimentation and can carry out continual separate the suspend liquid with density difference. The centrifuges which made by out factory can clarify, dehydrate and classify the suspensions with 0.002-3 mm solid-phase particles and thickness range at 0.5~40%. The product can be classify into two type LW-counter-current and parallel-current base on its structure feature. According to feed feature, product can be divide into LW two-phase separator, LWS three-phase separator.

Application:
Decanter centrifuge is most often used for clarification of liquid containing high concentrations of solid, removing solids from liquid. It is usually used in waste water and PVC sludge industry. And also can be used in sunflower oil, palm oil and tea industry.

Product competitive advantage:
1, Helical pusher adopts the special antifriction method: sprinkle hardness alloy or inlay hardness alloy anti-friction disk; anti –corrosion stainless steel is employed for the material of the main parts of drum, so that assure the durability and longer using lifetime of the equipment.
2, The decanter occupied little area, easy to be assembly and commissioning; the whole machine is operated hermetically, and has a good production environment.
3, Adopt double frequency conversion control for main motor and differentia auxiliary motor, so make stepless speed regulation come true as well as enlarge the scope of application.



Introduction of Company:



Juneng Group has set-up a 1st class in-house laboratory for chemical composition analysis, metallographic analysis, spectrum analysis, performance analysis, radiographic inspection, magnetism inspection, ultra-sonic inspection and etc. This is to imply with the latest advance instrumentations and rigorous working attitude to ensure every part of product is stable and reliable.





Product Specifications:

Model

Drum diameter
mm

Draw Ratio
L/D

Speed of drum
r/min

Factor of
separation G

Spiral difference
rotate speed

r/min

Inlet
capacity(m3/h)

Main/assist
motor (KW)

LW250

250

3.73

4200

2467

2~31

1-7

11/4

LW350

350

4.4

3600

2540

5~25

5~18

22/5.5

LW450

450

4.4

3200

2580

5~25

5~25

30/11

LW520

520

4.1

2850

2365

2~26

10~45

45/11
