TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud

China TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud supplier
TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud supplier TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud supplier TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud supplier TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud supplier

Large Image :  TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud

Product Details:

Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: ISO / CE
Model Number: TLB1.2/0.6-4-L-Y

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: USD$ 2985 / set
Packaging Details: Standard Wooden Case
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 40 set / months
Contact Now
Detailed Product Description
Other Name: Cam Metal Rotor Pump Drive: Motor
Motor Speed: 10-720 Rpm Motor Power: 0.25-2.2 Kw
Pressure: 0.1-1.2 Mpa Flow: 1.2 M3 / Hour



TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud





Product description:



Cam type rotor pump manufacturing standards are divided into: food grade, chemical grade, ordinary type, oil field type, special type five series.



Rotor and rotor, rotor and pump body to maintain a certain gap between the friction coefficient, long service life.



TLB Series Food Industry Stainless Steel Transfer Pump for yeast mud



After the use of special materials, can transport sludge, sewage and other media containing solid particles.



Can transport medium viscosity of ≤200 million cp, and solid content of 60% of the slurry.



Can be transported gas, liquid, solid phase mixed material.


Product Specifications:



Model Caliber DN (mm) Flow (m3 / h) Pressure (Mpa) Suction P (Mpa) Speed (r/m) Capacity (L/r)
TLB0.1 10 0.1 0.1-1.2 -0.08 10-720 0.01
TLB0.5 15 0.5 0.1-1.2 -0.08 10-720 0.04
TLB2 25 2 0.1-1.2 -0.08 10-720 0.15
... ... ... ... ... ... ...
TLB400 300 400 0.1-1.2 -0.08 10-300 40



Application:



It covers the most industries, such as Daily chemical, Fine chemicals,Food,Papermaking,Chemical fiber,Medicine and coating etc.



Working Principle:



The two conjugated metal cams of the cam pump are rotated in reverse synchronously by an external synchronizing gear, thereby discharging the liquid between them and the pump body.The cam pump is divided into single and multi-lobe cam pumps.



Between the cams and between the cam and the pump body are not in contact with each other, depending on the size of the pump and the temperature of the conveying medium leaving a corresponding gap.



Product competitive advantage:



The inner gearing principle is adopted for this pump. The annular and external gear pitch circles closely lean against one side, the other side is separated by covering with “ crescent plate” .



The annular gear driver the external gear for the same direction rotation. It has the advanced structure, fine quality, small volume, large flow, low noise, durable service life.



Delivery:



1. for the complete pump: packed with plastic to avoid wet and dust then put and fixed into the seaworthy wooden case



2. for spare parts of the pump: packed into carton box then expressed to the buyer



QA/QC Department



1.Factory visit/ audit is required prior to other purchase



2.Inspection of material is required during in process manufacturing & prior shipment



3.Compliance to technical requirements



Company detail



Juneng Group is a large scale manufacturer of industrial products in China. This group principally engaged with the in-house research & development as well as manufacturing of various industrial filters, separators , centrifuges and pumps.
